AI for Piping Estimation to Bid on 2x More Projects
The Takeoff AI does piping takeoff from P&IDs, line lists and isometrics, and returns a piping material takeoff with every valve, fitting and weld traced to its sheet, sized and classed by spec.
ASF uses The Takeoff AI to save 80% of the estimating time on a bid that runs around 45 hours.
Peter Sirois
Managing Director,
ASF - New England, US
TheTakeoff AI estimates projects the way you do
The Takeoff AI reads what actually arrives on the shared drive: PDFs. Clean vector sheets, scans, photocopies of photocopies. If you can open it, it can take off from it.
Valve and Instrument Takeoff
The Takeoff AI counts valves by their symbol on the piping and instrumentation diagram and reads the tag beside each one, so type, size and rating arrive attached to the count.
Isometric Takeoff
Derives lengths, fittings, flanges, valves, welds and spool breaks off each isometric, from both the bill of material table and the drawing.
General Arrangement Takeoff
The Takeoff AI measures line runs off the scaled general arrangement and picks equipment positions off the plan, marking each length as measured so you can see which numbers came off the scale.
Line list + Pipe Class sheets
The Takeoff AI reads the line list and pipe class sheets as the specification, so every measured line comes back carrying its class, material, schedule and insulation.
Fittings, Flanges and Welds
The Takeoff AI counts elbows, tees, reducers and couplings by size and schedule, and flanges by rating and facing.
How The Takeoff AI Does a Piping Takeoff
From the package landing on your shared drive to a priced bill of material in three steps.
Upload the Drawing Set
Drop in the package as it arrived, and The Takeoff AI scans every sheet, reading title blocks, revisions and the scale before it counts anything.
Piping Takeoff
It identifies every valve, fitting, flange and weld, classes each one against the line list, and measures lengths automatically. Works off isometrics, P&IDs and GA.
Get the Bill of Material
Quantities arrive grouped by line and spec, with bolts and gaskets derived, and every count links back to the sheet a reviewer can click into.
Price The Job Before Your Competitors Finish Counting
Watch P&ID and isometric takeoff run end to end, with every count traced to its sheet.
Book A Takeoff Walkthrough
